Commercial Air Conditioning

• 12.1 Inch Colour LCD touch panel with intuitive interface
• Annual and weekly schedules
• Advanced multi-level scheduling
• Control and monitor building air conditioning remotely
• Control and monitor up to 400 Indoor units with EW-C50E expansion module
• Energy monitoring*2 and tenant billing*3
• Integration and control of third-party equipment*4
• Simple single gateway for BMS integration*5
• Energy saving control functions
• Fast fault detection and maintenance alerts
• M series, Mr Slim, City Multi VRF HVRF and LOSSNAY unit control.

• Capacity range: 22 to 150 kW
• Reduced condenser footprint
• External static pressure up to 80 Pa
• Max. height difference up to 90 m
• Advanced “Low Noise” function

• Capacity range: 22 to 150 kW
• Reduced plant room sizes
• Existing water circuit re-use
• Individual indoor unit control option
• Centralised control option

City Multi YNW range is available in capacities from 22-124 kW and offers some of the highest levels of efficiency coupled with smaller footprints, reduced noise levels and increased design options.

City Multi YNW provides our lowest installation costs, running costs and CO2 emissions of a VRF system. This is achieved through the new 4-sided heat exchanger, compressor and fan design, improving both nominal and seasonal efficiency levels.

The new high efficiency models retain the unique flat tube aluminium micro-channel heat exchanger which is a pivotal step change in providing more effective and efficient heat transfer.

The CITY MULTI WR2 series provides all of the advantages of the R2 series with the added benefits of a water heat source system, making it suitable for wider range of applications in high rises, frigid climates, coastal areas, etc.

Not only does it produce heat recovery from the indoor units on the same 2-pipe refrigerant circuit, it also produces heat recovery via the water circuit between heat source units, making it a very economical system.

Branch Circuit Controller (BC Controller) is the technological heart of the CITY MULTI R2–Series. It works in unison with the outdoor unit to provide simultaneous cooling and heating, something no other two–pipe system can do.

The Hybrid VRF is part of the CITY MULTI product range, which consists of VRF air conditioning units that use refrigerant between the outdoor unit and the branch controller, and water between the branch box and the indoor units, designed for medium to large scale applications. Efficiency and reliability are at the very core of the Mitsubishi Electric Hybrid VRF systems.

• Capacity range: 22 to 56 kW
• R32 Refrigerant
• Reduced condenser footprint
• External static pressure up to 80 Pa
• Maximum height difference up to 90 m
• Advanced “Low Noise” function
• Extended operating range in cooling up to 52°C
