HMI
GOT2000 Series
The Mitsubishi Electric GT23 Series of graphic operator terminals are full of outstanding features you wouldn’t expect to find in an entry-level screen. With a simple and sleek design concept and long-life cycle components, the GT23 Series provides a TFT LCD display with 65K colours, VGA resolution, and 9 MB of internal memory. All GT23 models can be programmed with GT Works 3 engineering software, which allows users to configure and build modern applications with simple configuration.
65K colour TFT LCD display with VGA resolution available in the following screen sizes: 8.4” and 10.4”.
Standard features include communication interfaces such as Ethernet, RS-422/485, RS-232, USB host/device, and SD memory card.
Advanced features such as data logging, multi-channel communication and FA transparent function are supported.
| Specifications | GT2308-VTBA | GT2308-VTBD | GT2310-VTBA | GT2310-VTBD | |
|---|---|---|---|---|---|
| Display unit | Type | 8.4”, TFT, LCD, 65536 colours | 10.4”, TFT, LCD, 65536 colours | ||
| Resolution (pixel) | 640 x 480 | ||||
| Power supply | 100 – 240 V AC | 24 V DC | 100 – 240 V AC | 24 V DC | |
| Memory capacity | (ROM) | 9 MB | |||
| (RAM) | 9 MB | ||||
| Memory card | 1 (SD memory card) | ||||
| Keyboard type | Touch-panel | ||||
| Function keys | Touch keys | ||||
| LED indicators | 1 (power) | ||||
| Interfaces | Ethernet (TPC/IP), RS232, RS422/485, USB, SD card slot | ||||
| Real-time clock | Intergrated | ||||
| Network communication possibilities | Ethernet (TCP/IP), RS232, RS422/485 | ||||
| IP rating (front) | IP67* | ||||
| Dimensions (WxHxD) | mm | 241 x 194 x 56 | 303 x 218 x 56 | ||
| Weight | kg | 1.5 | 1.9 | ||
